3 Films

Triple Film X-Ray Viewer

Designed for efficiency and clarity, this 3-film viewer allows simultaneous display of multiple images—ideal for comprehensive diagnosis and review.

Main Features

• Triple-Panel Display: Supports up to 3 films at once

• Auto Sensor Lighting: Lights up when films are inserted, turns off when removed

• PWM Dimming: Adjustable brightness from 0–4500 cd/m²

• High-Brightness LED: Uniform, flicker-free illumination with 100,000h lifespan

• Durable Build: 4mm frosted acrylic panel with slim 25mm aluminum frame

• Flexible Mounting: Wall-mountable or bracket-supported

• Compatible Films: General, digital, and mammography films

Specifications

• Viewing Area: Large enough for 3 standard films

• Brightness Uniformity: ≥90%

• Power: AC90–240V, 50/60Hz

• Control: Stepless dimming via 3-digit PWM system
